AA-BOND F110 Transparent, Epoxy Adhesive, Rigid, Clear, Low Viscosity, Room Temperature Cure

$3.99

Brand Name:

Atom Adhesives

* Size:

2.5gm pouch(s)
5gm pouch(s)
10gm pouch(s)
100gm kit(s)
250gm kit(s)

Quantity:

TDS
Product Review
Find Similar Products by Category

Product Description

OPTICALLY TRANSPARENT LOW VISCOSITY EPOXY ADHESIVE

PRODUCT DESCRIPTION:

AA-BOND F110 is a rigid, optically clear adhesive with a very low viscosity.

AA-BOND F110 is room temperature system an excellent choice for thin bond-line assembly and repair applications of prisms, lenses and other optic components. And its high strength makes this epoxy ideal for structural applications.

AA-BOND F110 exhibits excellent wetting and wicking capabilities which allows it to adhere strongly to glass, ceramics, metals and most rigid plastics.

GENERAL PROPERTIES

Appearance	Transparent, clear
Cure Type	Room temperature or Heat cure
Benefits	High strength Perfect insulative properties Good resistance to salt solutions, mild acids and Alkalis and many other chemicals
Mix Ratio by weight	100:11 / Resin:Hardener
Operating Temperature	-60 to 130 C
Typical Applications	Exhibits excellent wetting and wicking capabilities which allows it to adhere strongly to glass, ceramics, metals and most rigid plastics.
Volume Resistivity	6.00e+13 ohm-cm

UNCURED PROPERTIES:

Viscosity @ 25 C	310
Thixotropic Index	1.0
Specific Gravity, mixed	1.16
Reactive solids contents, %	100
Pot Life	30 minutes

CURE SCHEDULE:

5 minutes	@ 100C
2 minutes	@ 120C
1 minute	@ 150C

CURED PROPERTIES:

Glass transition temperature (Tg), C	90
Hardness, Shore D	83
Refractive Index	1.54
Lap shear strength, psi	2150 (alum to alum, 24 hrs @ 25C) 2600 (alum to alum, 1 hr @ 65C) 3000( alum to alum, 4 hrs @ 65C)
Dielectric Constant	4.3 @ Frequency 1000 Hz
Dielectric Strength	16.1 kV/mm 410 kV/in

GENERAL INFORMATION:

For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS).

HOW TO USE:

1) Carefully clean and dry all surfaces to be bonded.

2) Apply AA-BOND F110 completely mixed adhesive to the prepared surfaces, and gently press these surfaces together. Contact pressure is adequate for strong, reliable bonds; however, maintain contact until adhesive is completely cured.

3) Some separation of components is common during shipping and storage. For this reason, it is recommended that the contents of the shipping container be thoroughly mixed prior to use.

4) Some ingredients in this formulation provided may crystallize when subjected to low temperature storage. A gentle warming cycle of 52C for 30 minutes prior to mixing components may be necessary. Crystallized epoxy components do not react as well as liquid components and should be re-dissolved prior to use for best results.

AVAILABILITY:

This epoxy can be supplied in various different packages.
