Product Description

FOOD AND DRUG APPLICATION EPOXY ADHESIVE

PRODUCT DESCRIPTION:

AA-BOND FDA2 is a medium viscosity epoxy resin system specifically developed for medical device applications. It has been tested in accordance with USP biological reactivity tests, in vivo and received Class VI approval.

AA-BOND FDA2 is two part amber adhesive used and cured at room temperature for bonding, laminating and repair applications by manufacturers of food preparation, processing and packaging equipment and devices.

AA-BOND FDA2 provides low permeability to gases and vapors, and good resistance to water, weather, petroleum solvents, lubricants, to mild acids and alkalis, and to many other organic and inorganic compounds.

GENERAL PROPERTIES

Appearance	Amber
Cure Type	Heat cure or Room Temperature
Benefits	Medium viscosity Class VI approved Easily mixed Low permeability Good resistance
Mix Ratio by weight	100:100 / Resin:Hardener
Substrates	Most metals, ceramic, glass and plastics
Operating Temperature	-70 to 145 C
Typical Applications	Bonding, laminating and repair applications by manufacturers of food preparation, processing and packaging equipment, and by manufacturers of catheters, hearing aids, dental products and other biomedical instruments and devices.
Minimum Service Temperature, Air	-94 F

UNCURED PROPERTIES:

Viscosity @ 25 C	14,000 2000
Specific Gravity, mixed	1.11
Reactive solids contents, %	100
Pot Life	45 minutes

CURE SCHEDULE:

1-4 hours	@ 65C
24 hours	@ 25C

CURED PROPERTIES:

Glass transition temperature (Tg), C	54
Hardness, Shore D	79
Dielectric strength volts/mil	420
Water Absorption, %	.004
Lap shear strength, psi	2700 (Aluminum to Aluminum)
Volume Resistivity	1.20e+14 ohm-cm
Dielectric Constant	3.4 @ Frequency 1000 Hz
Dissipation Factor	0.020 @ Frequency 1000 Hz

GENERAL INFORMATION:

For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS).

HOW TO USE:

1) Carefully clean and dry all surfaces to be bonded.

2) Apply AA-BOND FDA2 completely mixed adhesive to the prepared surfaces, and gently press these surfaces together. Contact pressure is adequate for strong, reliable bonds; however, maintain contact until adhesive is completely cured.

3) Some separation of components is common during shipping and storage. For this reason, it is recommended that the contents of the shipping container be thoroughly mixed prior to use.

4) Some ingredients in this formulation provided may crystallize when subjected to low temperature storage. A gentle warming cycle of 52C for 30 minutes prior to mixing components may be necessary. Crystallized epoxy components do not react as well as liquid components and should be re-dissolved prior to use for best results.

AVAILABILITY:

This epoxy can be supplied in various different packages.
