PRODUCT DESCRIPTION:
Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant is an impact resistant, fiber-optic adhesive.
Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant is two-part, low viscosity epoxy has the distinct advantage of remaining below 3000 cps for a minimum of 40 minutes.
Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant allows more connectors to be produced from one mix. Low stress, Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant is an excellent choice for multimode connectors and single mode connectors where excessive curing temperatures may cause cracking.
Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant can be cured at room temperature overnight or as fast as 15 minutes at 90C. The blue color facilitates easy polishing and its cured properties prevent pistoning. This product is a 100% solid system that can be used for small potting and sealing applications where resistance to thermal shock and impact are required.
GENERAL PROPERTIES
| Appearance | Blue |
| Components | 2 component - requires mixing |
| Mix Ratio by weight | 100:30 / Resin:Hardener |
| Benefits | Low viscosity
Thermal shock and impact resistant
Low stress connections |
| Cure Type | Room temperature or Heat Cure |
| Operating Temperature | -60 to 100 C |
| Typical Applications | Fiber optic assembly, multimode and single mode connectors, small potting and sealing applications |
UNCURED PROPERTIES:
| Viscosity @ 25 C | 2300 |
| Thixotropic Index | 1.0 |
| Specific Gravity, cured | 1.2 |
| Pot Life | 30 minutes |
CURE SCHEDULE:
| 24 hours | @ 25C |
| 1 hour | @ 65C |
| 15 minutes | @ 90C |
CURED PROPERTIES:
| Glass Transition Temperature (Tg), ultimate, C | 102 |
| Hardness, Shore D | 85 |
| Refractive Index | 1.51 |
| Water Absorption , after 24 hours saturation, % | 0.07 |
GENERAL INFORMATION:
For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS).
HOW TO USE:
1) Carefully clean and dry all surfaces to be bonded.
2) Apply Fiber-Optic-Bond 12 Fiber Optic Epoxy Adhesive, Two Part, Long Pot Life, Impact Resistant completely mixed adhesive to the prepared surfaces, and gently press these surfaces together. Contact pressure is adequate for strong, reliable bonds; however, maintain contact until adhesive is completely cured.
3) Some separation of components is common during shipping and storage. For this reason, it is recommended that the contents of the shipping container be thoroughly mixed prior to use.
4) Some ingredients in this formulation provided may crystallize when subjected to low temperature storage. A gentle warming cycle of 52C for 30 minutes prior to mixing components may be necessary. Crystallized epoxy components do not react as well as liquid components and should be re-dissolved prior to use for best results.
AVAILABILITY:
This epoxy can be supplied in various different packages.
